Dengan memadukan faktor bentuk yang sudah dikenal dengan set fitur yang tinggi, X-T20 dari Fujifilm adalah kamera tanpa cermin ramping yang dirancang untuk penembak multimedia. Dengan memanfaatkan sensor APS-C X-Trans CMOS III 24.3MP dan prosesor gambar X-Processor Pro, stills resolusi tinggi dapat direkam dengan ketajaman dan kejelasan yang mencolok karena tata letak organik sensor dan penghilangan filter low-pass optik. Kombinasi sensor dan prosesor juga memanfaatkan rentang sensitivitas yang diperluas ke ISO 51200, tingkat pemotretan 14 fps yang terus menerus saat bekerja dengan rana elektronik, dan kemampuan untuk merekam video UHD 4K atau Full HD 1080p. Saat bekerja dengan subjek yang bergerak, kinerja autofocus yang berkesinambungan telah dioptimalkan untuk pelacakan subjek yang lebih baik dan akurasi keseluruhan, dan mode Auto SR Lanjutan juga dapat digunakan untuk pengambilan gambar otomatis sepenuhnya dengan pengenalan adegan cerdas. Selain itu, desain bodi kamera retro yang menggabungkan layar sentuh touchscreen 3.0 "1.04m-dot serta jendela bidik elektronik 2.36m-dot, dan dial fisik tersedia untuk menyesuaikan pengaturan eksposur dan pengambilan gambar dengan cepat dan intuitif.
| Type | Mirorrless |
| Recording Media | SD Card (-2G) / SDHC Card (-32G) / SDXC Card (-256G) UHS-I*1 |
| Lens Mount | FUJIFILM X mount |
| Image Sensor | 23.6mm x 15.6mm(APS-C)X-Trans CMOS III with primary color filter. |
| Pixels | effective pixels 24.3 millions pixels |
| Aspect Ratio | 3:2 |
| Dust Deletion Feature | Sensor Cleaning system Ultra Sonic Vibration |
| Recording Format | JPEG (Exif Ver.2.3)*2, RAW : 14bit RAW(RAF original format), RAW+JPEG |
| File Size | L: (3:2) 6000 x 4000 / (16:9) 6000 x 3376 / (1:1) 4000 x 4000 M: (3:2) 4240 x 2832 / (16:9) 4240 x 2384 / (1:1) 2832 x 2832 S: (3:2) 3008 x 2000 / (16:9) 3008 x 1688 / (1:1) 2000 x 2000 <Panorama> |
| RAW + JPEG Simultaneous Recording | RAW+JPEG |
| Picture Style | 15 modes (PROVIA / Standard, Velvia / Vivid, ASTIA / Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Black& White, Black& White+Ye Filter, Black& White+R Filter, Black& White+GFilter, Sepia, ACROS, ACROS+Ye Filter, ACROS?R Filter, ACROS?G Filter) |
| White Balance Settings | Automatic scene recognition / Custom / Color temperature selection (K) / Preset : Daylight, Shade, Fluorescent light (Daylight), Fluorescent light (Warm White), Fluorescent light (Cool White), Incandescent light, Underwater |
| Viewfinder Type | 0.39-in., approx. 2,360K-dot OLED color viewfinder, Coverage of viewing area vs. capturing area : approx. 100% Eye point : approx. 17.5mm ( from the rear end of the camera's eyepiece), Diopter adjustment : -4m ~ +2m-1(dpt) Magnification : 0.62x with 50m |
| Depth Of Field Preview | Yes |
| Autofocus Type | Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF) |
| AF Points | Hybrid: 91 |
| Focusing Modes | Single point AF: EVF / LCD: 13x7 / 25x13 (Changeable size of AF frame among 5 types), Zone AF: 3x3 / 5x5 / 7x7 from 91 areas on 13x7 grid, Wide/Tracking AF: (up to 18 area) * AF-S : Wide * AF-C : Tracking |
| Metering Modes | Multi / Spot / Average / Center Weighted |
| Exposure Control Systems | TTL 256-zone metering |
| ISO Speed / Gain Range | Standard Output Sensitivity : AUTO1 / AUTO2 / AUTO3(up to ISO12800) / ISO200 to 12800(1/3 EV step) Extended output sensitivity : ISO100 / 25600 / 51200 |
| Exposure Compensation | -5.0EV - +5.0EV, 1/3EV step (movie recording : -2.0EV - +2.0EV) |
| Shutter Type | Focal Plane Shutter |
| Shutter Speeds | Mechanical Shutter 4 sec. to 1/4000 sec.(P mode), 30 sec. to 1/4000 sec.(All modes) Bulb mode(up to 60 min), TIME : 30 sec. to 1/4000 sec. Electronic Shutter*3 4 sec. to 1/4000 sec.(P mode) 1 sec. to 1/32000 sec. (P / A / S / M modes) Bulb mode : 1 sec. f |
| Self Timer | 10sec. / 2sec. |
| Camera Start-up Time | Approx 0.4sec. |
| Built in Flash Type | Manual pop-up flash (Super Intelligent Flash) |
| Guide Number | approx. 7 (ISO200 · m) / approx. 5 (ISO100 · m) |
| Drive Modes | P(Program AE) / A(Aperture Priority AE) / S(Shutter Speed Priority AE) / M(Manual Exposure) |
| Video File Format | MOV (MPEG-4 AVC / H.264, Audio : Linear PCM / Stereo sound 48KHz sampling) |
| File Size | [4K (3840x2160)] 29.97p / 25p / 24p / 23.98P, 100Mbps Continuous recording : up to approx. 10 min. [Full HD (1920x1080)] 59.94p / 50p / 29.97p / 25p / 24p / 23.98P, 36Mbps Continuous recording : up to approx. 15 min. [HD (1280x720)] 59.94p / 50p / 29.97p |
| LCD Monitor | Tilt-type TFT color LCD monitor (approx. 100% coverage) |
| Monitor Size | 3.0-inch |
| Monitor Pixels | approx. 1040K-dot |
| Interface Languages | 35 Languages |
| Display Format | RAW conversion, Image rotate, Auto image rotate, Face Detection, Red-eye removal, Photobook assist, Erase selected frames, Multi-frame playback (with micro thumbnail), Slide show, Protect, Crop, Resize, Panorama, Favorites |
| Direct Printing Compatible | instax printer print |
| USB Terminal | USB2.0 (High-Speed) / micro USB terminal * connectable with Remote Release RR-90 (sold separately) |
| Video Out Terminal | HDMI micro connector (Type D) Other ?2.5mm, stereo mini connector [Microphone] |
| Power Source | Battery |
| Battery Type | NP-W126S Li-ion battery (included) |
| Battery Life | Actual battery life of movie capture*5 *Face detection is set to OFF 4K: approx. 50 min., FULL HD: approx. 60 min. Continuance battery life of movie capture*5 *Face detection is set to OFF 4K: approx. 70 min., FULL HD: approx. 95 min. |
| Dimensions (W x H x D) | 118.4mm (W) x 82.8mm (H) x 41.4mm (D) / 4.66in. (W) x 3.26in. (H) x 1.63in. (D) (Minimum Depth : 31.9mm / 1.3 in.) |
| Weight | Approx. 383g / 13.5 oz. (including battery and memory card) Approx. 333g / 11.8 oz. (excluding accessories, battery and memory card) |
| Operating Environment Temp | 0°C - 40°C (+32°F - +104°F)C |
| Working Humidity | 10 - 80% (no condensation) |
